Porter Faze 3.0C (FZ-3.0C)

FZ-3.0C-view.jpg FZ-3(120V)a.jpg

Features

  • Smooth and stable smoke output control from 5-100%. In accordance with different wind power, the smoke can be adjusted from minimum to 100%. Suitable for operation in any locations.
  • 5-100% fan speed adjustment. Quiet and smooth fan let the smoke disperse unknowingly. 100% high fan speed let the smoke be thin and even, and expand more quickly throughout the location.
  • Primary heating up takes very short time, only about 45 seconds, shorter than general faze machines.
  • The machine can be installed for up spray or side spray.
  • Unique design of 5.6-liter liquid tank let FZ-3.0C have no worry of oil leaking when being operated up spray or side spray. Quick connector makes replacement direct and easier when performance is ongoing.
  • DMX on board, 3 DMX modes for choice; 1CH, 2CH, 4CH, operate by any additional DMX controller.
  • Built-in multi-function operation control. Built-In timer control, manual fogging control and continuous fogging control.
  • FZ-3.0C is equipped with 0~45 degree adjustable air deflector.
  • Heavy-duty. Able to keep working long time.
  • Self-cleaning function: The machine design of machine stops working after a delay of 30 seconds, automatically clear the tubing of the remaining liquid.
  • Design of expediting liquid supply: When low smoke output, it takes more time for supplying the liquid for the first time. The function of manual fogging is suggested to be used for expediting liquid supply and save time.
  • Easy understanding blue LCD screen and intelligent design of software control.
  • Flight case designed with thick and excellent material. Liquid tank designed for quick fixing and with protection against getting loosen during transportation. All details are required.
  • Can be connected with additional DMX wifi module.

>>> Read More

Porter Faze 3.0 (FZ-3.0)

FZ-3.0 FZ-3.0

Features

  • Smooth and stable smoke output control from 5-100%.  In accordance with different wind power, the smoke can be adjusted from minimum to 100%.  Suitable for operation in any locations.
  • 5-100% fan speed adjustment. Quiet and smooth fan let the smoke disperse unknowingly. 100% high fan speed let the smoke be thin and even, and expand more quickly throughout the location.
  • Primary heating up takes very short time, only about 45 seconds, shorter than general faze machines.
  • The machine can be installed for up spray or forward spray.
  • Unique design of 5.6 liter liquid tank let FZ-3.0 have no worry of oil leaking when being operated up spray or side spray. Quick connector makes replacement direct and easier when performance is ongoing.
  • DMX on board, 3 DMX modes for choice; 1CH, 2CH, 4CH, operate by any additional DMX controller.
  • Multi-function operation control. Built-In timer control, manual fogging control and continuous fogging control.
  • Heavy-duty.  Able to keep working long time.
  • Self-cleaning function: The machine design of machine stops working after a delay of 30 seconds, automatically clear the tubing of the remaining liquid.
  • Design of expediting liquid supply: When low smoke output, it takes more time for supplying the liquid for the first time. The function of manual fogging is suggested to be used for expediting liquid supply and save time.
  • Easy understanding LCD display and intelligent design of software control.
  • Rugged high-quality shape designed with strong bracket. Liquid tank designed for quick fixing and with protection against getting loosen during transportation. All details are required.

>>> Read More

DJ Fazer (FZ-2.0)

FZ-2.0 FZ-2.0

Features

  • Smooth and stable smoke output control from 5-100%.  In accordance with different wind power, the smoke can be adjusted from minimum to 100%.  Suitable for operation in any locations.
  • 5-100% fan speed adjustment. Quiet and smooth fan let the smoke disperse unknowingly. 100% high fan speed let the smoke be thin and even, and expand more quickly throughout the location.
  • Primary heating up takes very short time, only about 75 seconds, shorter than general faze machines.
  • DMX on board, 2 CH DMX, operate by any additional DMX controller.
  • Multi-function operation control. Built-In timer control, manual fogging control and continuous fogging control.
  • FZ-2.0 is equipped with adjustable smoke vent.
  • Self-cleaning function: The machine design of machine stops working after a delay of 30 seconds, automatically clear the tubing of the remaining liquid.
  • Design of expediting liquid supply: When low smoke output, it takes more time for supplying the liquid for the first time. The function of manual fogging is suggested to be used for expediting liquid supply and save time.
  • Easy understanding LED display and intelligent design of software control.
  • Heavy-duty.  Able to keep working long time.

Specifications

Name DJ Faze machine
Item No. FZ-2.0
Housing configuration Black & Blue iron case
Heater Power 700W
Consumption 720W
DMX512 CH. 2CH
Built-in Function.
  • Timing Fogging
  • Continuous Fogging
FUSE(120V) 10A/250V
FUSE(230V,240V) 5A/250V
Display LED Display
Tank(liters) 2L
Fog Output (cu.ft/min) 9000
Warm Up time(seconds) 75s
Fluid Consumption (ml/min) MAX. output 10ml/min
Date Connection 3P XLR
Power Connection IEC Socket
Low Fluid Shutdown Yes
Bracket Yes
Dimensions/mm(LxWxH w/o bracket) 378 x 317 x 310mm
Weight(kg) 6
Voltage 120V,230V,240V 50/60Hz

Video

Sorry, Not yet available

Further Information

Porter Faze (FZ-3.0)

FZ-3.0 FZ-3.0

Features

  • Smooth and stable smoke output control from 5-100%.  In accordance with different wind power, the smoke can be adjusted from minimum to 100%.  Suitable for operation in any locations.
  • 5-100% fan speed adjustment. Quiet and smooth fan let the smoke disperse unknowingly. 100% high fan speed let the smoke be thin and even, and expand more quickly throughout the location.
  • Primary heating up takes very short time, only about 45 seconds, shorter than general faze machines.
  • The machine can be installed for up spray or forward spray.
  • Unique design of 5.6 liter liquid tank let FZ-3.0 have no worry of oil leaking when being operated up spray or side spray. Quick connector makes replacement direct and easier when performance is ongoing.
  • DMX on board, 3 DMX modes for choice; 1CH, 2CH, 4CH, operate by any additional DMX controller.
  • Multi-function operation control. Built-In timer control, manual fogging control and continuous fogging control.
  • Heavy-duty.  Able to keep working long time.
  • Self-cleaning function: The machine design of machine stops working after a delay of 30 seconds, automatically clear the tubing of the remaining liquid.
  • Design of expediting liquid supply: When low smoke output, it takes more time for supplying the liquid for the first time. The function of manual fogging is suggested to be used for expediting liquid supply and save time.
  • Easy understanding LCD display and intelligent design of software control.
  • Rugged high-quality shape designed with strong bracket. Liquid tank designed for quick fixing and with protection against getting loosen during transportation. All details are required.

Specifications

Name Porter DMX Faze machine
Item No. FZ-3.0
Housing configuration Black iron case
Heater Power 1400W
Consumption 1500W
DMX512 CH. 1CH, 2CH, or 4CH
Built-in Function.
  • Timing Fogging
  • Continuous Fogging
  • Manual Fogging
FUSE(120V) NFB 16A
FUSE(230V,240V) 10A/250V
Display Blue LCD Screen
Tank(liters) 5.6L
Fog Output (cu.ft/min) 15000
Warm Up time(seconds) 45s
Fluid Consumption (ml/min) MAX. output 16ml/min
Date Connection 3P or 5P XLR
Power Connection Direct Power Cord
Low Fluid Shutdown Yes
Bracket Yes
Dimensions/mm(LxWxH w/o bracket) 394 x 434 x 253mm
Weight(kg) 10.6
Voltage 120V,230V,240V 50/60Hz

Video

Sorry, Not yet available

Further Information

DJ Faze 2.0 (FZ-2.0)

FZ-2.0 FZ-2.0

Features

  • Smooth and stable smoke output control from 5-100%.  In accordance with different wind power, the smoke can be adjusted from minimum to 100%.  Suitable for operation in any locations.
  • 5-100% fan speed adjustment. Quiet and smooth fan let the smoke disperse unknowingly. 100% high fan speed let the smoke be thin and even, and expand more quickly throughout the location.
  • Primary heating up takes very short time, only about 75 seconds, shorter than general faze machines.
  • DMX on board, 2 CH DMX, operate by any additional DMX controller.
  • Multi-function operation control. Built-In timer control, manual fogging control and continuous fogging control.
  • FZ-2.0 is equipped with adjustable smoke vent.
  • Self-cleaning function: The machine design of machine stops working after a delay of 30 seconds, automatically clear the tubing of the remaining liquid.
  • Design of expediting liquid supply: When low smoke output, it takes more time for supplying the liquid for the first time. The function of manual fogging is suggested to be used for expediting liquid supply and save time.
  • Easy understanding LED display and intelligent design of software control.
  • Heavy-duty.  Able to keep working long time.

>>> Read More

Porter Faze (FZ-3.0C)

FZ-3.0C-view.jpg FZ-3(120V)a.jpg

Features

  • Smooth and stable smoke output control from 5-100%. In accordance with different wind power, the smoke can be adjusted from minimum to 100%. Suitable for operation in any locations.
  • 5-100% fan speed adjustment. Quiet and smooth fan let the smoke disperse unknowingly. 100% high fan speed let the smoke be thin and even, and expand more quickly throughout the location.
  • Primary heating up takes very short time, only about 45 seconds, shorter than general faze machines.
  • The machine can be installed for up spray or side spray.
  • Unique design of 5.6-liter liquid tank let FZ-3.0C have no worry of oil leaking when being operated up spray or side spray. Quick connector makes replacement direct and easier when performance is ongoing.
  • DMX on board, 3 DMX modes for choice; 1CH, 2CH, 4CH, operate by any additional DMX controller.
  • Built-in multi-function operation control. Built-In timer control, manual fogging control and continuous fogging control.
  • FZ-3.0C is equipped with 0~45 degree adjustable air deflector.
  • Heavy-duty. Able to keep working long time.
  • Self-cleaning function: The machine design of machine stops working after a delay of 30 seconds, automatically clear the tubing of the remaining liquid.
  • Design of expediting liquid supply: When low smoke output, it takes more time for supplying the liquid for the first time. The function of manual fogging is suggested to be used for expediting liquid supply and save time.
  • Easy understanding blue LCD screen and intelligent design of software control.
  • Flight case designed with thick and excellent material. Liquid tank designed for quick fixing and with protection against getting loosen during transportation. All details are required.
  • Can be connected with additional DMX wifi module.

Specifications

Name Porter DMX Faze machine
Item No. FZ-3.0C
Housing configuration With flight case
Heater Power 1400W
Consumption 1500W
DMX512 CH. 1CH, 2CH, or 4CH
Built-in Function.
  • Timing Fogging
  • Continuous Fogging
  • Manual Fogging
FUSE(120V) NFB 16A
FUSE(230V,240V) 10A/250V
Display Blue LCD Screen
Tank(liters) 5.6L
Fog Output (cu.ft/min) 15000
Warm Up time(seconds) 45s
Fluid Consumption (ml/min) MAX. output 16ml/min
Date Connection 3P or 5P XLR
Power Connection PowerCON
Low Fluid Shutdown Yes
Bracket No
Dimensions/mm(LxWxH w/o bracket) 533 x 387 x 249mm
Weight(kg) 21.3
Voltage 120V,230V,240V 50/60Hz

Video

Sorry, Not yet available

Further Information

SMART LED SCAN (SSC-3L)

The creative Smart LED Scan excites the market with its high-quality performance, amazing economic benefits and fashionable designs. Equipped with 30W good quality white LED, switching power and Backlight LED display, and supported by standard DMX control, master/slave control and stand-alone control systems, Smart LED Scan is a reliable assistant for any excellent performance..

SSC-3L SSC-3L

Features

  • SSC-3L is equipped with 30W white LED of high quality. Better brightness. Extremely long-life light source (>20,000 hr. Rated), no bother of bulb replacement.
  • Unique and patented pan-tilt high speed scanning mirror module.
  • 11 colors +open on one wheel, 9 gobos +open on another wheel, precision in stepper motor moving mirror projection.
  • LED control displays operating DMX setting, built-in function selection.
  • USITT standard DMX control, master/slave control and stand-alone control.
  • Excellent cooling system.
  • Stylish plastic housing design.

Specifications

Model No. Smart LED Scan (SSC-3L)
Illuminant 30W white LED
Gobos+Colors 11 colors + open
9 gobos + open + black out
(two wheels)
Motor Stepping motor
Effect Strobe 0.5~12fps
Gobo & Color change
Scan Mirror
DMX Channels 6
Audio Control (internal mic) YES
Dimensions (LxWxH) 460x185x195mm
Weight 3.1kg
Voltages Available AC100~AC240/50Hz/60Hz
Fuse T2A/250V
Power Consumption 60W

Effect

SSC-3L SSC-3L

Key To Symbols

Video

Manual Download

Sorry, Not yet available

MD-3

MD-3 is a metal LCD Display controller of Timing and Volume Control, simultaneously capacitating for DMX512 setting function. It simply controls fogging output, puffing interval and duration. Master/Slave control of various units is functional. Cable length is 10M with 5pin XLR connector.

Controller-For-Fog-Machine-DC-3S.jpg MD-3

FUNCTION: Select first DMX address, Interval, Duration, Volume, Master, Channel, then have the numerical value changed by using UP and DOWN buttons.

DMX address: Setting of DMX address, pressing UP/Down button at the same time have the number return to”0”.

Interval: Setting of Interval time from 10s~250s, effective as starting the Timer function.

Duration: Setting of Duration time from 1s~15s, effective as starting the Timer function.

Volume: Setting of fogging volume from 10% ~ 100%, effective as starting the Timer function.

Master: When connecting all Fogs by DMX, set this unit to ON as the Master giving order. They are all controlled by the Timer, Hold, Manual in the display. Any other DMX controller be excluded at this moment, nor does other Master set to ON. Channel becomes the single one, DMX address all set to 001.

Channel: Switching DMX as one or three channels. Only “Volume” function if with single channel.

Specifications

Model MD-3
Cable Length 10 M
Connector 5 Pin XLR
Function LCD DMX Control – DMX address, Interval, Duration,
Volume, Master, Channel setting.
Dimensions (L x W x H) 164x76x33mm
Weight 800g
Compatible with) MX-1800, MX-3500

Key To Symbols

Video

Sorry, Not yet available

Further Information

ATMOS FOG (AF-1000)

The Atmos 1000 is a 650W compact, high output fog machine with new advances in technology. It has a special heating element design that uses an oil type transmission throughout the pipeline to prevent clogging. It is also equipped with a high performance pump system for optimum output.

The Atmos 1000 also has convenient features such as a visible fog fluid level built-in to the rear of the unit to see how much fluid is in the tank, and a LED heating indicator system that changes colors depending on whether the fogger is heating up or ready to use.

>>> Read More

FAZE 1.0 (FZ-1.0)

FAZE 1.0 is high efficiency of heating. It is compact for easy movement. It can make volumes of harmless and dry haze that is perfectly suitable for matching with any kind of traditional lightings, LED lightings and Lasers in any performance.

FAZE 1.0 is equipped with 0~45 degree adjustable smoke vent, die-cut heating module, quiet fan and big liquid tank. The heating module of high efficiency allows FAZE 1.0 to make volumes of haze in a short time and to disperse the haze evenly in the whole space. When detected low liquid by the patented sensor device, power cutting functions automatically to prevent interior spare parts from damage. The fan is quiet and effective. The dry and long lasting haze effect makes FAZE 1.0 excellent for matching with any kinds of lightings. TC-4 timer controller is further options to elevate the utility of FAZE 1.0.

>>> Read More

MARS DMX Fog Machines (MX-3000DX)

MARS DMX Fog Machines provide superior performance due to:

  • Built-in function of timing control allows easy timing control volume, interval, and duration through by LED display.
  • Humanized warning function for abnormal status: In case the fogger has any abnormal functioning, the LED display on the back panel and status of tank will be indicating abnormal status as warning to let the user be aware of the problematic situation in time.
  • Aluminum die-cast design functioned with high-effective heating module prevents clogging. Unique design that can be earthed directly without affecting normal working of the thermo system and DMX control circuit. There won’t be danger of accidental human body’s electric shock.
  • Advanced oil-level sensor detects shortage of oil and warns the pump to cut the oil supply automatically.
  • DMX on board, operate by any additional DMX controller.
  • Manual fogging can be operated directly from the back panel of the machine. Manual fogging is prior to other fogging operations of the easy controller & built-in timing function.
  • High output fog machine, approx. 40000 cu.ft/min output.
  • Electronic Thermo Sensing (ETS) – electronic heater stay hot at all times between fog blasts.
  • Direct thermal protection.
  • Master / Slave mode can be operated either by the built-in timing control or by outside connected controller. Simple and humanized design makes the fogger easier for use.

>> Read More

MARS Professional DMX Fog Machine Series

All deliberate designs have accomplished MARS as products of preeminence.

MARS series, DMX digital foggers, establish their eminence in the market with unique innovation and professional technique. Thanks to their high security and easy maintenance, MARS series are perfectly adapted for locations of professional performance. There are our optional models:MX-1000MX-1250MX-1500MX-1800 and MX-3500, with the following five characteristics:

Easy Maintenance

The entire machine is assembled with a heat module, a pump module and a circuit module. The innovative design completely solves the problem that the circuit and other parts interfere with one another while dismantling for update, maintenance or repair. Each of the three modules is independent, and does not affect the others, and that is what makes the maintenance so direct and easy. At the same time, you can easily disassemble the lateral sides to take out the broken heating module or the pump module, or the rear side to replace the circuit module. Such intelligent and ideal design makes the maintenance most humanized and simple.

Security

The one-piece die-cast heating module is perfectly covered and sealed with iron shell. Even under such circumstances as the fixture is over heating or the secure parts is out of control, no hazard will happen. Furthermore, the patented oil-level sensor detects shortage of oil and warns the pump to cut oil supply automatically so as to prevent from damaging or accidentally firing.

High Efficiency

The one-piece die-cast heating module fastens heat transmission and therefore, shortens the heating cycle. The break-through design of double heating pipes for MX-1800 & MX-3500 even enhances significantly the heating efficiency.

Economical Power Consumption

Power-saving device enables MX-1800 and MX-3500 to cut automatically power consumption during stand-by, which impressively realizes power saving up to 50%.

Convenience

MARS is a series of DMX digital foggers which can be conveniently connected with other Foggers and DMX stage equipment for operation. Besides, the series can be operated by exteriorly connected controllers (e.g. TC-3X or MD-3) to control fogging time and volume or Master/Salve operation. Our high-quality fog liquid is a perfect match for the series to maximize the fogging effect.
